Alternator bolt

I believe itis a 50 Torx, be careful not to strip it

GENERATOR
Removal
Disconnect negative cable at battery.
Disconnect generator lead wire ("B" terminal wire) and coupler from generator.
Remove generator belt. See GENERATOR BELT .
Remove generator drive belt adjusting bolt and generator mounting bolt.
Remove generator.
Installation
Mount generator on the generator bracket.
Tighten generator bolts (upper bolt "1", lower bolt "2") to specification. See TORQUE SPECIFICATIONS .
Install generator (cooling fan) belt. See GENERATOR BELT .
Connect "B" terminal wire "3" and coupler to generator. Tighten "B" terminal outer nut "b" to the specification. See Fig. 18 .
Install canister.
Connect negative cable at battery.

It is a torx T50 but good luck. Mine is stripped too. I am going to try to take holding bracket off and work with it on bench.

Electrical problem
2002 Suzuki XL7 4 cyl Two Wheel Drive Automatic

what tool do i need to remove lower alternator bolt

So do you need to know what size socket to remove the bottom bolt i don't have detail's about that in my repair manual's.Or are you having trouble getting the bolt out by being able to get a socket on the bolt.Let me know. I believe it is a 50 Torx

I need a detailed instruction on changing my alternator. I can not afford a mechanic and have limited mechanical knowlege. however i am genuinley handy at do-it your self projects. Please help I need my truck back.
thanks Paul

PS. I would be happy to make a donation but my checking account is negative at the moment and unless I can get to work it will not get better. I do pledge to donate once I am back in the black. Hope some one can help out a guy temporarily down on his luck

I would so appreciate it if any-one could send a reply to my email address. make sure to include a means to show you my appreciation once I am back on track. [email protected]

GENERATOR
Removal
Disconnect negative cable at battery.
Disconnect generator lead wire ("B" terminal wire) and coupler from generator.
Remove generator belt.
Remove generator drive belt adjusting bolt and generator mounting bolt.
Remove generator.
Installation
Mount generator on the generator bracket.
Tighten generator bolts (upper bolt (1), lower bolt (2)) to specification.
Install generator (cooling fan) belt.
Connect "B" terminal wire (3) and coupler to generator. Tighten "B" terminal outer nut (b) to the specification. See Fig. 17.
Install canister.
Connect negative cable at battery.
