Serpentine belt

2003 CHEVROLET MONTE CARLO
180,000 MILES • 3.4L • V6 • 2WD • AUTOMATIC
Avatar
VICTORIA MONTIJO
  • MEMBER
  • 1 POST
My A/C compressor locked up on my car. is there anyway to reroute the belt as a temporary fix until I can get the cash to replace the compressor? Diagram please. Someone help.
Feb 9, 2017 at 4:03 PM
Advertisement
Avatar
STEVE W.
  • CERTIFIED EXPERT
  • 15,113 POSTS
No way to do that without a bypass pulley to take the place of the AC compressor. The belt has to go under the water pump pulley to drive it and the AC compressor is what holds it there.

I looked and did not find a bypass specifically listed for that vehicle.
Plus those are almost half of the price of a replacement compressor as well.
Feb 9, 2017 at 4:53 PM
Avatar
CJ MEDEVAC
  • CERTIFIED EXPERT
  • 11,004 POSTS
Got to be flexible!

Did the compressor lock up?

Or did the pulley lock up?

Compressor locked- unplug the wires to the clutch assembly- now it cannot engage-the pulley will spin.

Pulley locked- Go to a salvage yard, locate another compressor, if the compressor is shot, no problem, it is the pulley free-spinning you need (but the whole assembly is needed).

A little sweet talking/coffee/soft drinks really steers the cash register in your favor, after all, you just want a bad part anyway! (When I go to my regular spots, they expect a Coke or Mountain Dew, I get off free or just a few dollars-For instance, $10.00 for my Mom's car door!)

Use this cheap/free compressor unit as a by-pass pulley.

Just do not plug it in!

Even better, destroy the connector on the donor compressor so no one else can plug it in.



The Medic

Image (Click to enlarge)
Attached Media
Feb 9, 2017 at 5:16 PM
