starter removal

Here is a guide that will help walk you through the process.

https://www.2carpros.com/articles/how-to-replace-a-starter-motor

Please let us know if you need anything else to get the problem fixed.

1999 oldsmobile bravada won't crank or start seems like i am getting power to everything. i check fuses and replaced starter

**No crank at all/nothing/nada when key is engage to starting position

Could be the starter, starter relay, clutch switch/park and neutral switch/transmission position switch and ignition switch assuming the battery condition and connections are good. Note:If it doesn't apply disregard.

need help getting it out of a small area

Upon removal of starter, note if any shims are used. If shims are used, they should be reinstalled in their original location during replacement. If starter is noisy during cranking, remove one .015 inch double shim or add one .015 inch single shim to the outer bolt. If starter makes a high pitched whine after firing, add .015 inch double shims until noise ceases.


Disconnect battery ground cable.
Raise and support front of vehicle.
Remove any shields or braces blocking access to the starter, on 4.3L/V6-262 raise vehicle half way to gain access to starter.
On 4-wheel drive vehicles, remove skid plate if equipped.
Remove bolts and brackets holding brake line to crossmember.
Remove crossmember.
On all models, remove starter mounting bolts, then allow starter to drop down.
Remove solenoid wiring and battery cable, then the starter assembly.
Reverse procedure to install.
