Need to know to what degree I turn the cylinder head bolts and torque specs.
Oct 10, 2024 at 12:18 AM
cylinder head bolt torque specs?
2020 CHEVROLET MALIBU
PANCHOJONEZ
- MEMBER
- 1 POST
- FOLLOW
Advertisement
Here are the cylinder head tightening torque specs and the sequence as well in the images below. These are torque to yield bolts so you will need new ones before reassembly.
first pass: 30 nm (22 lb ft)
final pass: 240 degrees
Check out the images (below). Let us know if you need anything else.
first pass: 30 nm (22 lb ft)
final pass: 240 degrees
Check out the images (below). Let us know if you need anything else.
Image (Click to enlarge)
Oct 10, 2024 at 1:08 PM
