Air conditioner Not Blowing Cold Air.

2000 CHRYSLER CONCORDE
196,000 MILES • FWD • AUTOMATIC
Avatar
STEFFYMANNING
  • MEMBER
  • 2 POSTS
The air conditioner does not blow cold air. We have recharged it, changed fuses, and still will not blow cold air. It is blowing hot hot hot air, which is good for the winter, but not with spring and summer here.
Apr 20, 2016 at 4:08 PM
Advertisement
Avatar
CJ MEDEVAC
  • CERTIFIED EXPERT
  • 11,004 POSTS
MAYBE ITS A PROBLEM WITH A BLEND DOOR OR DOOR ACTUATOR ON OR INSIDE THE UNIT, NOT ALLOWING A DOOR TO "SWITCH" TO THE PROPER DUCTING

THE MEDIC
Apr 20, 2016 at 4:24 PM
Avatar
STEFFYMANNING
  • MEMBER
  • 2 POSTS
How much am I looking at to fix something along these lines?
Apr 20, 2016 at 4:49 PM
Advertisement
Avatar
CJ MEDEVAC
  • CERTIFIED EXPERT
  • 11,004 POSTS
THERE ARE SO MANY THINGS THAT COULD KEEP THE DOOR(S) FROM MOVING

IT COULD BE MECHANICAL (LIKE A DOOR BROKEN OR A LINKAGE FROM AN ACTUATOR POPPED LOOSE OR A FRIED ACTUATOR)

AS FAR AS ELECTRICAL OR ELECTRONIC GOES BODY MODULE, THE PCM, AND A BUNCH OF OTHER INBETWEENS

UNTIL IT IS DIAGNOSED, THERE'S NO WAY OF ATTEMPTING A QUOTE (SORRY :-( )

HERE'S MY LAST DITCH EFFORT TO GET YOU OUT CHEAP!

I PONDERED THRU "PRODEMAND"s WIRE DIAGRAMS FOR YOUR VEHICLE

BOTH MANUAL AND AUTO A/C HAD THE SAME FUSES FOR THE SYSTEM

17, 23, 21,

AND 19 (WHICH WAS THE ONLY EXTRA ON THE AUTOMATIC SYSTEM)(WON'T HURT TO CHECK 19 REGARDLESS)

THESE FOUR FUSES ARE ON THE LEFT END OF THE DASH

UNDER THE HOOD

CHECK "B" AND "E"

LEFT SIDE OF THE ENGINE COMPARTMENT

THAT IS EVERYTHING I COULD FIND, FUSE-WISE, TO THE HVAC

RETURN WITH GOOD NEWS!

THE MEDIC

Image (Click to enlarge)
Attached Media
Apr 20, 2016 at 7:15 PM
