1990 Ford Tempo 2.3 belt tensioner replacement---how to do it?

THIS MAY BE BETTER THAN TEXT!

http://www.youtube.com/watch?v=Wg1AX77xEBQ


LET ME KNOW IF THIS HELPS

THE MEDIC

Thanks for the reply. While the video is infomative, it doesn't quite depict the situation on my Tempo. The motor he is working on is quite different from mine. I need to actually replace the tensioner assembly, not just the belts. And on the engine depicted in this video, there is much more clearance to access the tensioner mounting bolts.

NOT HAVING DONE THIS FEAT ON YOUR VEHICLE

I SEARCHED FOR ABOUT 45 MINUTES IN MITCHELL I

REMOVAL WAS MENTIONED IN 2 PLACES--(SEE 1ST PIC)....NOT MUCH THERE

MENTIONED AGAIN IN "ENGINE REMOVAL" IT SIMPLY SAYS: "REMOVE TENSIONER"....(AFTER THE ENGINE IS OUT OF THE CAR)

I KNOW THIS MUST FRUSTRATE YOU AND YOU WANT STEP BY STEP INSTRUCTIONS-----I'M GIVING YOU ALL I CAN FIND---AND MAYBE SUGGESTIONS TO COMPLETE YOUR TASK DIY (LIKE!) I TOO WOULD FROWN UPON A BIG SHOP OR THE STEALERSHIP DOING THIS "NOT SO HARD JOB" AND LEAVING WITH THAT "VICTIM" SHATTERED LOOK!

THIS IS A TYPICAL PIC OF YOUR TENSIONER (PIC 2)

PIC 3 IS THE FRONT VIEW OF THE ENGINE

I FOUND ANOTHER VIDEO WITH A 2.3 ENGINE--THE TENSIONER LOOKS TO BE IN ANOTHER LOCATION.....MIGHT HELP SOME.......WHAT YOU WILL REALLY LIKE!!!........THE NARRATOR SEEMS TO BE A MIME!!!

http://www.youtube.com/watch?v=KTDkgmNo40w

IF YOU WILL CHANGE/ ADD/ REARRANGE/ SUBTRACT WORDS IN MY SEARCH ------ EVEN SCROLL THRU SUGGESTIONS DOWN THE SIDE---YOU MIGHT FIND MORE RESULTS THAT MAY WORK FOR YOU.

THIS HAS/STILL DOES WORK FOR ME--I BUY ANY I DON'T ALREADY HAVE...SEE THIS POST AND MY ANSWER AT THE END

https://www.2carpros.com/questions/2000-ford-taurus-wondering-car-shakes-about-10-15-minutes-start-morning

HERE ARE SOME, "PLEASE ASSIST ME FOR FREE OR A SMALL GRATUITY", THINGS YOU MIGHT LOOK INTO

https://www.2carpros.com/questions/1999-infiniti-q45-replace-rear-o2-sensor

LET US KNOW YOUR PROGRESS, OR IF I MIGHT TRY MORE

SORRY I COULD NOT FIND MORE IN THE ONLINE MANUAL

THE MEDIC

I succesfully replaced the belt tensioner assembly. On this car, because of the tight clearance on the right hand side of the engine, it was necessary to do the following:

1) Remove the alternator
2) Remove cruise control assembly from right fender
3) Place jack under oil pan to support engine
4) Remove top plate from right-hand motor mount (two bolts on top, one nut reached from underneath car
5) Raise engine about 3 inches, to allow access to tensioner attaching bolts.

Hope this helps someone in the future.

Correction on the right motor mount top plate removal---there are also two stud nuts on the top that need to be removed. A total five fasteners to remove top plate---2 bolts and 3 stud nuts (one from underneath).

Thanks for the head sup. Closing thread.
