1989 MAZDA B2200
Avatar
ANONYMOUS
  • MEMBER
  • 1 POST
How do you replace a transmission modulator on a 1989 Mazda b2200?
Apr 10, 2013 at 9:21 PM
Advertisement
Avatar
HMAC300
  • CERTIFIED EXPERT
  • 48,601 POSTS
The manual doesn't give specific instructions for replacement of the vacuum modulator. Most are held in by a single bolt and a hold down clamp, simply remove them and pull the modulator out. I would advise you to keep an eye out for the small rod in the center of the modulator, they sometimes get lost or don't make it into the new one which will cause shifting issues.

Exploded diagram of the transmission is attached below
Apr 11, 2013 at 1:24 PM
